121 Steel Pipe & Parts CAD Blocks
Thank you for your purchase!
Make drawing pipework faster and easier. Download the blocks, add them to your tool palette and drag the parts you need into your model space to create professional steel pipeline drawings in minutes. It's that simple.
View all the parts in the viewer.
Why you'll love it
- Reducers, reducing TEEs, equal TEEs, 90 degree elbows, 45 degree elbows, pipe, sockets and flanges
- DWG files work with AutoCAD and similar programs
- Sizes from 25mm to 300mm NB (Nominal Bore)
- Dynamic blocks that adjust to your needs
- Every part shows front, top and side views
- Clear English labels on every part
- 121 ready-to-use pipe parts
Why you'll love it
- Save hours of drawing time (I spent 100+ hours creating these)
- Perfect for plumbers, engineers and designers
- Professional looking drawings every time
- No more drawing pipes from scratch
Important Disclaimer
This product is a drawing library tool and may not include every part variation from all manufacturer catalogues. Some parts might look different or be missing compared to your supplier’s catalogue, as each supplier can have their own versions or specifications.
You are responsible for checking all dimensions, specifications, and compatibility for your specific project. Always verify details with your supplier before using these drawings in a final design. Parts may need small adjustments to match your supplier’s exact products.
The seller is not responsible for any errors, differences, or issues that result from using these files. Use at your own risk and always confirm with your supplier before ordering or building.
